Product Specification

Processor: 12th Gen. Intel® Alder Lake Core i3-1215UE (default) Optional: i5-1235U, i5-1245UE, i7-1255U, i7-1265UE, Celeron® 7305E Memory: 2 x 262 pin SO-DIMM up to 64GB Dual Channel DDR5 4800 MHz BIOS: AMI UEFI 64 Mbit Display Interface: 2 x HDMI 2.0b: 4096 x 2160@60Hz Display output max: 4 independent or clone Internal: 1 x M.2 2242/2280 Key M PCIe x4 (NVMe) or SATA III (6Gb/s) 1 x SATA III (6Gb/s) for 2.5" SSD (option) Audio Codec: Realtek ALC888s-VD 2-channel WLAN: Intel WiFI Module (802.11 a/b/g/n/ac) & BT 5.0 (Option) Realtek RTL8821CE 802.11a/b/g/n/ac + Bluetooth 4.2 WLAN card M.2 2230 E key (Option) External antenna (Dipole) x2 (Option) LAN: 2 x RJ-45 (10/100/1000Mbps/2.5GbE) Supports Wake On LAN Serial Ports: 1 x RS-232 (DB-9) 2 x RS-232/422/485 (DB-9) (RS232 with power supply :ring in/ 5V (standard) &12V (with specific optional board) USB: 4 x USB3.2 Gen 2 (Type A)/ 4 x USB2.0 Audio: 1 x Line-out / 1 x Mic-in Type: 1. 19V (without wide range board) 2. With wide range board, MB support 9-36V DC-in Adapter: BPCAL02: 19V/4.74A 90W external adapter BPCAL03: 19V/7.89A 150W external adapter OS Support: Windows 10 / 11 IoT 64bit Linux 64bit Dimension (WxHxD): 245 x 57 x 169mm Weight: 2.85 kg Operating Temperature: BPCAL02: 0 ~ 40°C / BPCAL03: -20 ~ 60°C Storage Temperature: -20°C ~ 80°C Relative Humidity: 10% - 90% RH (non-condensing) EMC: CE, FCC, VCCI, BSMI, RCM, UKCA Safety: cTUVus, CB, CEC, BSMI, UKCA Mounting: VESA Mount 75 x 75 mm (Screws Option) Ear Mount 256 x 100 mm (Option) Din Rail Mount 35 mm (Option)
